EPW-45 pallet washing system

SKU: EL83105000
Category: Pallet washing systems

Description
Others (1)

'[vc_row][vc_column width="1/2"][vc_column_text] <h1>EPW-45 pallet washing system</h1> <ul> <li>Capacity of 70 pallets per hour.</li> <li>Pallet size (LxWxH): <ul> <li>1200 x 800 x 120 mm., dwell time 150 seconds and</li> <li>1200 x 1000 x 120 mm., dwell time 120 seconds.</li> </ul> </li> <li> 24 month guarantee on material and construction defects</li> </ul> <h2>Safeties:</h2> <ul> <li>Sensors on the hatches of the washing tunnels: as soon as a hatch is opened, the system stops</li> <li>Emergency switch on the control cabinet</li> <li>Water level switch to prevent the pumps run dry</li> <li>Torque protection on the drive: if the transport blocks, the drive stops</li> <li>Protective cap over the drive and rotating parts.</li> </ul> <h2>Description:</h2> The entire system is constructed from solid plates and profiles (stainless steel 304 - material number 1.4301.) and stands on adjustable feet. The washing tunnel is accessible using a practical removable hatch. The pallets are fed into the washing tunnel via a loading module. A plastic conveyor belt transports the pallet on the short side. A large number of nozzles guarantee optimal cleaning of the pallets. The side guides ensure that the pallets are well positioned during the cleaning process. Sensors on the hatches switch the pallet washing system off immediately if a hatch is opened during operation. The system is controlled via a Siemens logo, which is located in a stainless steel control cabinet. <strong>Main washing zone:</strong> In the main washing zone, the pallets are cleaned and the dirt on the pallets is removed. In the main washing zone, the stainless steel nozzles are configured for maximum cleaning results. They are fed by a powerful, energy-saving pump. Before the rinsing water flows back into the tank for reuse, it is thoroughly filtered through a filter drawer. The filter drawer is easy to remove, making the spacious water tank easily accessible. The main washing tank is filled via a filling connection with a level gauge. This level gauge switches off the water supply as soon as the operating level is reached. An overflow prevents the water level from becoming too high. A manhole is installed for quick and convenient cleaning of the water tanks. A ball valve is installed for emptying the main washing tanks. This allows the tank to be emptied quickly and safely. The water tank is designed with a floor gradient for quick emptying. <strong>Rinse zone:</strong> In the rinse zone, the pallets are rinsed with clear water. The rinse arch is equipped with stainless steel nozzles. The water supply is connected to the water network and equipped with a rinse control. [/vc_column_text][/vc_column][vc_column width="1/2"][vc_column_text]<strong>Type: EPW-45</strong> Output: 70 pallets/hour Connection: 400V
